Direct airflow where you need it
180° MULTI-DIRECTIONAL AIR-OUTPUT CONTROL AT YOUR FINGERTIPS

Scag's exclusive NDS (Nozzle Direction System) provides unprecedented control of the air-discharge vertical tilt and horizontal rotation.

Fingertip Switches
DUAL HORIZONTAL-ROTATION CONTROLS

Adjust the nozzle's rotation up to 180 degrees using an Auto Left/Right Switch and a Fine-Tune Switch.

Convenient Manual Lever
VERTICAL-TILT CONTROL

Adjust the tilt of the discharge nozzle up to 16 degrees: lower to help loosen and blast stubborn debris or higher to prevent blowback.

Massive Air Output
6,000 / 7,500 CFM

Massive air output of up to 6,000 effective CFM (Cubic Feet per Minute) (7,500 theoretical peak CFM) provides incredible ground-clearing force on a variety of surfaces and applications.

Fabricated and Balanced, 23", 8-Blade Impeller
RELIABLE PERFORMANCE AND SMOOTH OPERATION

Heavy-duty blower construction ensures years of dependable service and worry-free performance. The 23"³ steel, 8-blade impeller is dynamically balanced for smooth operation. The impeller mounting utilizes a tapered locking hub.

Large, Dual Air Intake
KEEP IT MOVING

Built with a front and rear air intake. Housing is aerodynamically designed to optimize intake without causing turbulence.

Controls and Instrument Panel
YOU'RE IN COMMAND

Proven, ergonomic drive-control lever's design provides incredible ease-of-use. Instrument panel features NDS, ignition switch, PTO switch, throttle control, choke control and Scag's exclusive Tiger Eye™ Advanced Monitoring System.

Model
WS23-37BV-EFI

Engine
Briggs Vanguard™ BIG BLOCK™ "“ electronic fuel injection

HP
37 HP

Fuel Capacity/Tank
8 Gallons

CFM Output
Effective CFM "“ 6,000
Theoretical Peak CFM "“ 7,500

Frame Construction
All-steel, welded 10-gauge

Impeller Construction
All-steel, welded, 8-blade, dynamically balanced

Impeller Mounting
Tapered locking hub

Impeller Diameter/Width
23" / 8.5"

Blower Housing Construction
All-steel, welded, 12-gauge front and side housing plate and 10-gauge back housing plate

Blower Housing Width
10"

Discharge Tube
69 square inches

Front Wheel(s)
13" x 5"-6", flat-free

Rear Wheels
24" x 12"-12", 4-ply

Accessories
Light Kit, Chrome Wheel Covers, Air Filter Monitor

Length
71.5"

Width
51"

Height
47.25"

Weight
943 lb

Warranty
2-Year Commercial; 2-Year Residential; 90-day Rental

MSRP
$13,381
