4-Blade Impeller
FABRICATED AND BALANCED, 20-INCH, 4-BLADE IMPELLER

Within the unit's 6"³-wide housing is a welded-steel impeller with 3/8"³-thick steel blades. Dynamically balanced for reduced vibration, longer life and less stress on the engine, these loaders boast an effective, high-output (up to 3,075 CFM), debris-reducing design.

Smart Construction and Convenient Serviceability
EASY ACCESS FOR WEAR PLATE AND IMPELLER SERVICE

1/4"³-thick, bolt-in, replaceable wear liner extends service life. Removable rear-housing cover allows easy access to impeller and wear plates.

Locking Boom Arm and Intake Nozzle
SAFE AND CONVENIENT TRANSPORT

Transport lock safely secures the boom arm and hose when not in use; nylon bearing delivers smooth movement. A transport pin locks the nozzle to the loader to help protect the hose during transportation.  Quick-detach hose also allows for quick and easy transport, storage and cleaning.

Ambidextrous Nozzle Handle
EASY HANDLING FROM EITHER SIDE: THE CHOICE IS YOURS

Padded, large-diameter handle is designed for increased leverage and easy maneuverability.

10" Steel Intake Nozzle
TAKE IT ALL IN

Large, replaceable intake nozzle is beveled to make debris pickup easy.

Skid-Mount
STANDARD 4" SKID RISERS

Four-inch skid risers with fork pockets have multiple install points to fit a wider variety of applications, or they can be completely removed.

Hitch-Mount (Optional)
OPTIONAL SWING-AWAY HITCH-MOUNT ACCESSORY

Swing-away design allows the loader to move for dumping/removing debris from the truck. There are three (3) locking positions for exceptional versatility. Fits TLS20-18BV model only.

Fuel Capacity/Tank
1.75 gallons "“ engine-mounted metal tank

CFM Output
3,075

Frame Construction
All-steel, welded

Impeller Construction
4-blade, 1/2"-thick blades, all-steel, welded

Impeller Mounting
Straight bore

Impeller Diameter/Width
20" / 5.25"

Blower Housing Construction
Removable back panel for easy impeller and wear plate access

Blower Housing Width
6"

Blower Housing Wear Plates
Standard: 1/4"-steel, replaceable

Hose Specifications
120" length, 10"-diameter intake hose, 0.045 black thermoplastic rubber, wire helix with wearstrip

Unit Mounting
4" steel skid risers

Discharge Tube
Clear thermoplastic, 7" diameter

Throttle Control
Commercial-grade, all-steel mechanicals, plastic debris cover

Height
74.25" (without skid or hitch mount attached)

Weight
437 lb

Warranty
2-Year Commercial; 2-Year Non-Commercial; 90-Day Rental

MSRP
$5,100
