The envy of the neighborhood
48", 52" OR 61" CUTTING WIDTH
The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge on 48"³, 52"³ and 61"³ widths. An Advantage Cutter Deck is featured on 32"³ and 36"³ widths.

Ogura PTO Clutch Brake
STRONG, ADJUSTABLE CLUTCH FOR LONG LIFE
Provides excellent starting and stopping power for the cutter deck and an adjustable air gap for long life.

Adjustable Operator Platform
EXPERIENCE AN UNMATCHED, ULTRA-COMFORTABLE RIDE
The spacious operator platform delivers a smooth ride and reduces operator fatigue. Adjustable suspension spring can be moved forward or backward, with, or without, the spacer plate installed to meet the operator"™s comfort preference. Extra-large, extra-thick operator comfort cushion ensures comfortable operation, hour after hour.

Cutter-Deck Lift System
CONVENIENT, SPRING-ASSISTED LEVER
Cutter deck can be lifted and locked into transport position from the operator"™s station. Cutting heights are easily set by placing the tethered pin at the desired height.

High-Strength Steel Frame
SOLID DESIGN FOR YEARS OF DEPENDABLE SERVICE
Heavy-duty, single-tube, steel main-frame construction delivers superior strength and ensures years of trouble-free service. The front caster-wheel weldments are replaceable.

Industrial-Grade Hydraulic System
SPEEDS UP TO 10.5 MPH
48"³, 52"³ and 61"³ models: Dual Hydro-Gear pumps (12 cc) and Parker wheel motors (14 ci) deliver dependable power, with speeds up to 10.5 mph. Pump shock valves ensure reliability and long life. Cooling fans help maintain safe operating temperatures.

32"³ and 36"³ models: Dual Hydro-Gear pumps (10 cc) and Parker wheel motors (12 ci) deliver dependable power, with speeds up to 8.5 mph.

Ease of Maintenance
MORE UPTIME
Easy-to-remove covers, an unrestricted engine compartment, easy-to-reach grease Zerks and many more features make servicing the V-Ride™ II simple, so you can be in the shop less and on the job more.

• Total Fuel Capacity
  8 gallons (48", 52", and 61")
• Drive Tires
  24" x 9.5"-12" (48" and 52")
• Caster Tires
  13" x 5"-6" (48" and 52")
• Seat
  Extra-large comfort cushion
• Drive System Type
  Dual Pump and Motor
• Pumps
  Hydro-Gear 12 cc (48", 52", and 61")
• Motors
  Parker 14 ci (48", 52" and 61")
• Forward Ground Speed
  10.5 mph (48", 52" and 61")

• Reverse Ground Speed
  5 mph
• Parking Brake
  Hand lever
• Cutting Widths
  52"
• Cutting Height
  1.5" to 4.5" in .25" increments
• Deck Lift
  Hand lever
• Construction


  Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2" of steel. Reinforcement plates at cutter deck spindles.
  32" model features dual-plate.

• Spindles
  Cast-iron housing with tapered roller bearings.
