The envy of the neighborhood
52", 61" OR 72" CUTTING WIDTH

The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge. This deck is equipped with Scag's ultra-tough cast-iron spindles featuring tapered roller bearings and a top-mounted grease fitting with a relief valve to prevent over-greasing.

Driveshaft-Driven Cutter Decks

ANOTHER REASON THE TURF TIGER IS KING OF THE JUNGLE.
A driveshaft connects the engine to the deck, eliminating the long belt drive and increasing cutting-height range.

Heavy-Duty, Double-Tube Steel Main Frame
SOLID DESIGN FOR YEARS OF DEPENDABLE SERVICE

The Turf Tiger™ is ultra-strong and built for long life. It has a wide mower stance and extra-low center of gravity for ultimate stability and a replaceable front caster-wheel weldment.

Industrial-Grade Hydraulic System
SPEEDS UP TO 12 MPH

Dual Hydro-Gear pumps (16 cc) and Parker wheel motors (18 ci) deliver dependable power. Pump shock valves ensure reliability and long life. Cooling fans help maintain safe operating temperatures.

Auxiliary Hydraulic Oil Cooler
EFFICIENT OPERATION AND ADDED RELIABILITY

Standard-equipment oil cooler extends system life by keeping the hydraulic oil cooler. Cooler location utilizes the engine airflow to draw cool air through the cooling fins.

Command-Comfort Operator Station
THE TURF TIGER COMMAND-COMFORT OPERATOR STATION IS BUILT AROUND YOU.

Components include a torsion-spring suspension seat mounted on a 4-iso-mount system, Quick-Fit™ adjustable steering levers, and an adjustable deck-lift pedal.

Tiger Eye Advanced Monitoring System
KEEP A REAL-TIME "EYE" ON IMPORTANT SYSTEM FUNCTIONS

Depending on the mower model and engine selection, the Tiger Eye™ Advanced Monitoring System monitors a wide variety of systems in real-time, giving you valuable information in just a glance, right from the operator's seat.

• Total Fuel Capacity
  12 gallons (Gas/Diesel)

  33.5 lb (LP)

• Drive Tires
  26" x 12"-12" (61" and 72")
  26" x 9.5"-12" (52")

• Caster Tires
  13" x 6.5"-6"

• Seat
  4-point iso-mounted torsion-spring suspension seat

• Drive System Type
  Dual Pump and Motor

• Pumps
  Hydro-Gear: 16 cc

• Motors
  Parker: 18 ci

• Forward Ground Speed
  12 mph (Gas/LP)
  10 mph (Diesel)

• Reverse Ground Speed
  6 mph

• Parking Brake
  Adjustable foot-operated pedal. AUSCO disc brakes.



• Cutting Widths
  52", 61" and 72"

• Type
  Velocity Plus™

• Cutting Height
  1.5" to 6" in .25" increments

• Deck Lift
  Adjustable foot-operated pedal

• Construction
  Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2" of steel. Reinforcement plates at cutter deck spindles.

• Spindles
  Cast-iron housing with tapered roller bearings.

• Blade Engagement
  Ogura GT3.5 (300 ft lb)
  Ogura GT5 (350 ft lb) (Briggs Models)
  Adjustable air-gap for extended life.
