Description

Heavy-duty and built to perform, the Bobcat® DT20 places seeds directly into soil slits for fast germination and unmatched seed-to-soil contact, aeration, and overseeding.
  • Overseed with confidence. Seed flow rate is easily controlled right from the operator’s station and stops automatically when the reel is raised.
  • Adjust durable cutting blades down to a depth of .25 in. while seeding at variable rates for different grass varieties and applications.
  • Experience maximum germination with curve-shaped discs that place seeds directly into soil slits for unmatched seed-to-soil contact.
  • Finish jobs without feeling exhausted with self-propelled operation, delivering a consistent ground speed that makes for better results.
  • Independent ground and reel drive options with a transport lever make it easy to move around the jobsite.

Specifications

Brand:
Bobcat

More Specifications

Engine ModelHonda GX390
Engine Horsepower11.7 hp
Engine Displacement23.7 in³
Fuel Capacity1.6 gal
Included Blade ReelSeeding Blade; (10) 8-point, high-carbon, heat-treated blades, w/ 2" (51 mm) spacing
Drive4L-section V-belt to front wheels by gear box and sealed roller chain; triple 3V-section V-belts engine to reel
ClutchSpring loaded belt tightener
Gearbox22:1 reduction
Max Operating Speed2.4 mph
Seeding SystemSeed is dropped directly into soil slits via seed delivery tube and covered in soil by disc system
Seed Hopper Capacity40lb
Operating Width19"
Slicing Depth0.2"
Reel Speed3,200 RPM
Reel Height AdjustmentMicrometer screw; adjustable up to 1.25" (32 mm) for blade wear
Optional Flail Blade ReelHardened high-carbon steel blades:
  • 1/8" (3 mm) at 1" (25 mm) spacing
Optional Fixed Blade ReelHardened high-carbon steel blades:
  • 1/32" (1 mm) at 1/2" (13 mm) spacing
  • 1/32" (1 mm) at 1" (25 mm) spacing
  • 1/16" (2 mm) at 1" (25 mm) spacing
  • 1/16" (2 mm) at 1-1/2" (38 mm) spacing
FrameWelded 7-gauge steel
Front Tire(s)(2) 4.10/3.50 - 4 turf-tread pneumatic drive wheels
Rear Tire(s)(2) 4.10/3.50 - 4 sawtooth-tread pneumatic
Length50"
Width35.5"
Height44"
Weight453 lb

Replaces

{"Bobcat/Ryan":["544873"]}
Bobcat D20OV DT20 20" Walk-Behind Dethatcher & Overseeder replaces these OEM part numbers:

Fits These Models

Additional Information

Product Questions

Customer Questions
Bobcat D20OV DT20 20" Walk-Behind Dethatcher & Overseeder currently has 0 product question(s).

Reviews

Warning Cancer and Reproductive Harm www.P65Warnings.ca.gov

This is a genuine Bobcat product. Sohars is an authorized Bobcat dealer.

Bobcat D20OV DT20 20" Walk-Behind Dethatcher & Overseeder

Bobcat
D20OV

  • Overseeder with dethatching capabilities through a simplified transition process to exchange flail reels between the functionality.
  • Cover 18,700 square feet per hour with a 19 in. working width
  • Without any tools, easily change between five different reel types
  • Self-propelled operation

Price: $9,999.00
